Product Overview
▔▔The Atos SDHI series represents a high-performance line of spool-type proportional directional valves designed for precise, electronic directional and speed control in demanding hydraulic systems. Positioned as a core solution within Atos's premium proportional valve portfolio, the SDHI series combines direct-operated high-response solenoids with high-precision spool-sleeve designs. It delivers smooth, stepless fluid throttling and direction switching, making it ideally suited for high-precision hydraulic control scenarios such as closed-loop motion control, synchronized cylinder driving, and real-time pressure-flow adjustment in heavy industrial machinery.
Key Advantages
▔▔- Compact high-performance solenoid design delivering strong magnetic force for precise spool actuation under full system pressure.
- Reduced pressure losses through optimized internal flow channels, increasing overall system energy efficiency.
- Modular coil and valve structure allowing flexible interchangeability, quick field maintenance, and effortless coil replacement without opening the hydraulic circuit.
- Excellent dynamic response with stable switching performance across broad flow and temperature operating conditions.
Technical Specifications
▔▔
| Parameter | Specification / Range |
| Valve Size / Nominal Size | CETOP 03 / NG6 (ISO 4401 size 03) |
| Max Operating Pressure (Ports A, B, P) | Up to 350 bar (5075 psi) |
| Max Operating Pressure (Port T) | Up to 210 bar (3045 psi) |
| Max Flow Rate | Up to 80 L/min (21.1 US gpm) |
| Hysteresis | Less than 3 percent |
| Response Time (Switch On) | 30 ms to 50 ms (depending on fluid viscosity and pressure) |
| Response Time (Switch Off) | 20 ms to 40 ms |
| Fluid Temperature Range | -20 deg C to +60 deg C (standard NBR seals) / -20 deg C to +80 deg C (FKM seals) |
| Ambient Temperature Range | -20 deg C to +70 deg C |
| Recommended Viscosity Range | 15 to 100 mm2/s (cSt) |
| Max Permissible Viscosity | Up to 400 mm2/s (cSt) |
| Fluid Cleanliness Class | ISO 4406 class 20/18/15 (NAS 1638 class 9 recommended) |
Configuration Options
▔▔- Spool Configurations: Standard 3-position center options (closed center, open center, float center, tandem center) and 2-position spring-return or detent configurations.
- Control / Actuation Method: Direct electro-magnetic actuation via high-efficiency AC or DC solenoids.
- Electrical Connection Options:
- Standard DIN 43650 3-pin connector (IP65 protection degree).
- AMP Junior Timer or Deutsch connectors for mobile and harsh environment applications.
- Optional LED indicator lights and surge suppressor diodes inside the plug.
- Power Supply Voltages:
- DC Voltages: 12V DC, 24V DC, 110V DC, 220V DC.
- AC Voltages: 110V AC / 50-60Hz, 230V AC / 50-60Hz.
- Feedback and Monitoring: Optional mechanical emergency manual override button or lever; optional electronic position monitor switch for safety-critical circuits.
- Mounting Pattern: Subplate mounting according to ISO 4401-03-02-0-05 standards.
Key Materials and Components
▔▔
- Valve Body: High-strength cast iron body processed with precision shell moulding and internal honing to achieve minimal spool clearance and high wear resistance.
- Spool Material: Hardened alloy steel, precision ground and micro-finished to reduce internal leakage and prevent friction wear under continuous load.
- Solenoid Tube Assembly: Heavy-duty stainless steel wet-pin armature tube providing exceptional corrosion resistance and pressure tightness.
- Seals: Standard NBR (Nitrile) seals for mineral-based hydraulic oils; optional FKM (Viton) seals for synthetic fluids or high-temperature operating conditions.
Packaging and Transport Protection
▔▔
- Individual Industrial Packaging: Each valve unit is thoroughly cleaned, oil-flushed, and sealed in a heavy-duty anti-static VCI anti-corrosion polybag to prevent dust ingress and surface oxidation during transit.
- Shock-Absorbing Enclosure: Securely nested inside custom-fit molded foam or corrugated protective boxes to prevent surface scratches and impact shock during long-distance transportation.
- Master Export Carton and Palletization: Bulk shipments are packaged into multi-wall reinforced export cartons, strapped onto ISPM-15 compliant heat-treated wooden pallets, and wrapped in thick stretch film for complete weather resistance.
Applications
▔▔- Plastic Injection Molding Machines: Controls core pullers, ejector pins, and clamp auxiliary motion with exact timing and minimal switching shock.
- Metal Stamping and Hydraulic Presses: Serves as pilot or direct directional control for slide positioning, die cushion control, and hydraulic clamping logic.
- CNC Machine Tools and Machining Centers: Manages workpiece fixture clamping, tool changer hydraulic circuits, and spindle head positioning.
- Mobile Construction Machinery: Used in hydraulic control blocks for outrigger deployment, steering assistance, and auxiliary tool attachment control in excavators and cranes.
Related Models
▔▔
| Model Code | Description | Nominal Size | Max Pressure | Max Flow |
| SDHI-0631/2 23 | 2-position solenoid valve, spring-return, standard spool | NG6 / CETOP 03 | 350 bar | 80 L/min |
| SDHI-0711 23 | 3-position solenoid valve, closed center spool | NG6 / CETOP 03 | 350 bar | 80 L/min |
| SDHI-0713 23 | 3-position solenoid valve, open center spool | NG6 / CETOP 03 | 350 bar | 80 L/min |
| SDHI-0714 23 | 3-position solenoid valve, float center spool | NG6 / CETOP 03 | 350 bar | 80 L/min |
| SDHI-0631/2/A 23 | 2-position solenoid valve with manual emergency override | NG6 / CETOP 03 | 350 bar | 80 L/min |
| SDHI-0711/FI 23 | 3-position solenoid valve with position sensor switch | NG6 / CETOP 03 | 350 bar | 80 L/min |
FAQ
▔▔Q: Can the SDHI solenoid coils be replaced without draining the hydraulic system?
A: Yes. The SDHI series utilizes wet-pin solenoids. Coils can be safely unscrewed and replaced without opening the fluid chamber or releasing hydraulic system pressure.
Q: What type of hydraulic fluid is compatible with Atos SDHI valves?
A: Standard units with NBR seals are compatible with mineral-based hydraulic oils (HL, HLP). For synthetic fluids, fire-resistant fluids, or elevated temperatures, specify optional FKM seals.
