Guangdong Yanhui Hydraulic Co., Ltd. is one of the leading manufacturers and suppliers of parker pavc pump in China. We warmly welcome you to wholesale bulk parker pavc pump for sale here from our factory. If you have any enquiry about pricelist and quotation, please feel free to email us.
High-Efficiency Hydraulic Power Solution
Core Advantages
- Intelligent Pressure-Flow Compensation (PFC) Control
Equipped with advanced Pressure-Flow Compensation technology for dynamic balance between flow and pressure, achieving 35% faster response time.
- Wide Displacement Range
33–100 cm³/rev continuously adjustable displacement, catering to applications from precision injection molding to heavy-duty construction machinery.
- Industrial-Grade Reliability
High-pressure cast iron housing optimized via 3D stress simulation, compliant with EN 1563 standards for impact resistance, and MTBF exceeding 20,000 hours.
- Energy Efficiency Optimization
Patented port plate design reduces no-load losses, delivering 93% system efficiency (ISO 4409 certified).
Performance Specifications
| Model | Displacement | Power @ 210 bar | Noise @ 1,800 RPM | Max Speed | Flow @ 21 bar |
|---|---|---|---|---|---|
| PAVC33 | 33 cm³/rev (±0.5%) | 28.5 HP / 21.3 kW | 75–79 dB(A) | 3,000 RPM | 39.4 LPM (10.4 GPM) |
| PAVC38 | 38 cm³/rev (2.3 in³) | 33 HP / 24.6 kW | 75–79 dB(A) | 3,000 RPM | 45.0 LPM (11.9 GPM) |
| PAVC65 | 65 cm³/rev (4.0 in³) | 57.8 HP / 43.1 kW | 77–81 dB(A) | 3,000 RPM | 78.7 LPM (20.8 GPM) |
| PAVC100 | 100 cm³/rev (6.1 in³) | 95.5 HP / 71.2 kW | 83–85 dB(A) | 2,600 RPM | 119.6 LPM (31.6 GPM) |
Industrial Applications
- Precision pressure control for injection molding machines
- Hydraulic drives for mining equipment
- Marine deck machinery systems
- Wind turbine pitch control units
- Steel continuous casting systems
Technological Innovations
- Adaptive Swashplate Mechanism
Dual-spring preloaded swashplate design reduces pressure pulsation to <±2% of rated value (verified per ISO 10767-1).
- Modular Maintenance Design
O-ring face seals enable 40% faster disassembly compared to traditional designs.
- Smart Diagnostic Interface
CANopen/J1939 protocol support for remote monitoring and predictive maintenance.
Environmental Compatibility
- Operating temperature: -20°C to +90°C (optional low-temperature start-up kit)
- Protection class: IP66 (motor-mounted versions)
- Fluid compatibility: Mineral oil / HFD fluids / Biodegradable oils
