Product Overview

▔▔

The Rexroth PV7 Series is a high-performance, variable displacement, pilot-operated or directly operated hydraulic vane pump designed for precise flow and pressure regulation in open-circuit industrial and mobile hydraulic systems. Positioned as a mid-to-high pressure standard variable displacement pump within Bosch Rexroth's hydraulic portfolio, the PV7 series provides efficient fluid power control by continuously adjusting displacement according to system load demand.

Technical Specifications

▔▔

Parameter / Feature	Value / Specification	Unit / Condition
Displacement Range	10 to 150	cm3/rev
Maximum Operating Pressure	Up to 160 (Continuous) / Up to 210 (Peak)	bar
Rated Speed Range	900 to 1800	rpm
Operating Temperature Range	-20 to +80	Celsius
Hydraulic Fluid Viscosity Range	16 to 160 (Recommended) / 10 to 800 (Permitted)	mm2/s (cSt)
Hysteresis	Less than 1.5	% of maximum pressure
Response Time (On-stroke / Off-stroke)	30 to 80	ms
Noise Level	58 to 68	dB(A) at 1500 rpm / 100 bar
Required Fluid Cleanliness Class	ISO 4406 Class 18/16/13 or NAS 1638 Class 7	-

Applications

▔▔

Plastic Injection Molding Machines: Executes low-noise pressure holding, clamp cylinder movement, and injection displacement control while maintaining high energy efficiency during long dwell cycles.
Metal Stamping Presses and Shears: Provides rapid pressure compensation and reliable fluid displacement regulation for auxiliary positioning and hydraulic hold-down cylinders.
CNC Machine Tools and Machining Centers: Manages hydraulic tool changers, workpiece clamping units, and index table positioning with minimal pulsation and zero temperature spiking.
Die Casting & Forging Equipment: Delivers smooth pressure transition and rapid power supply for core-pulling mechanisms and hydraulic auxiliary ejectors.

Related Models

▔▔

Model Code	Displacement (cm3/rev)	Max Pressure (bar)	Control Type	Frame Size
PV7-1X/10-14RE01MC0-05	10	160	Direct Pressure Compensator	Size 1
PV7-1X/16-20RE01MC0-05	16	160	Direct Pressure Compensator	Size 1
PV7-1X/25-30RE01MC0-05	25	160	Direct Pressure Compensator	Size 2
PV7-1X/40-45RE01MC0-05	40	160	Direct Pressure Compensator	Size 2
PV7-1X/63-71RE01MC0-05	63	160	Pilot-Operated Pressure Control	Size 3
PV7-1X/100-118RE01MC0-05	100	160	Remote Pressure Control	Size 4
PV7-1X/150-175RE01MC0-05	150	160	Load Sensing / Pressure Control	Size 5

FAQ

▔▔

Q1: How do I verify the exact model code when replacing an existing PV7 pump?

A: Locate the metal nameplate riveted to the main housing of your current Rexroth pump. Note down the full model string (e.g., PV7-1X/25-30RE01MC0-05) and the 10-digit material code (MNR, starting with R or 0511...). Sending a clear picture of the nameplate to our technical team ensures an accurate 1:1 match or direct functional equivalent.

Q2: What is the recommended fluid cleanliness level for operating Rexroth PV7 pumps?

A: To ensure maximum service life and prevent premature vane or cam ring wear, the hydraulic fluid must maintain a cleanliness level of ISO 4406 Class 18/16/13 or better (equivalent to NAS 1638 Class 7). A suction line strainer and a high-efficiency return line filter (10 micron absolute) are strongly recommended.

Q3: Which types of hydraulic fluid are compatible with the standard PV7 pump?

A: Standard PV7 pumps with FKM (Viton) seals are fully compatible with mineral-oil-based hydraulic fluids (HL, HLP according to DIN 51524), synthetic esters (HEES), and environmentally acceptable hydraulic fluids. For water-glycol or special fire-resistant fluids, please consult our engineering department for seal modifications.
