Product Overview
▔▔The Parker BE Series represents a high-performance proportional directional control valve line engineered for demanding electro-hydraulic applications. Positioned as a premier industrial solution, the BE Series provides continuous, dynamic control of fluid flow rate and direction in response to electrical input signals. Featuring direct-acting or pilot-operated proportional spool mechanisms with integrated electronic control options, this series is optimized for closed-loop motion, precision positioning, speed regulation, and smooth force switching across modern hydraulic systems.
Key Advantages
▔▔- High-Dynamic Response: Advanced electromagnetic coil design and optimized spool geometry deliver rapid switching speeds and minimal response delay for tight machine control cycles.
- Superior Control Accuracy: Low hysteresis and high repeatability ensure exceptional fine-metering capability across all proportional control ranges.
- Integrated Electronics (OBE Options): Available with onboard driver electronics to simplify wiring, reduce signal noise, and streamline system integration.
- Robust Construction: Cast iron body paired with wear-resistant internal components offers high pressure ratings up to 350 bar and reliable duty cycles in harsh industrial environments.
- Flexible Configuration: Broad range of spool configurations, signal standard options, and mounting patterns conform to international standards such as ISO 4401 / CETOP / NFPA.
Technical Specifications
▔▔
| Parameter | Specification / Value | Unit |
| Max. Operating Pressure (Port P, A, B) | 350 (5075) | bar (psi) |
| Max. Tank Pressure (Port T) | 210 (3045) | bar (psi) |
| Nominal Flow Rates (@ Δp = 5 bar per metering edge) | 8, 16, 32, 80 (varies by size/spool code) | L/min |
| Max. Permissible Flow Rate | Up to 100 (depending on frame size) | L/min |
| Operating Fluid Temperature Range | -20 to +80 (-4 to +176) | °C (°F) |
| Fluid Viscosity Range | 12 to 380 | cSt (mm²/s) |
| Hysteresis | < 1.5% to < 3.0% | % of full signal |
| Repeatability | < 1.0% | % of full signal |
| Response Time (Step Response 0–100%) | 15 to 40 (configuration dependent) | ms |
| Fluid Cleanliness Class | ISO 4406 (18/16/13) or better | ISO Class |
| Supply Voltage | 24 (18 to 30 range) | V DC |
| Protection Class | IP65 / IP67 (with correctly installed plug) | IEC standard |
Configuration Options
▔▔
Mechanical Structure: Subplate mounting matching ISO 4401 / CETOP 03 (NG06) or CETOP 05 (NG10) standards for universal block installation.
Control Method:
- Analog Current Signal: 0–10 V, 4–20 mA, or ±10 V.
- Fieldbus Digital Control: Optional CANopen or EtherCAT interfaces on digital onboard electronics versions.
Spool & Position Feedback Options:
- Open-Loop Control: Standard proportional solenoid actuation without LVDT position transducer.
- Closed-Loop Control: High-precision version equipped with an inductive LVDT spool position transducer for dynamic closed-loop feedback.
Spool Configurations:
- Overlapped center (zero-leakage center position).
- Zero-overlap / Linear metering spools for precise velocity control.
- Symmetric (A and B equal flow) or Asymmetric (2:1 flow ratio for differential cylinders).
Electrical Configurations:
- Standard 6+PE main connector.
- Diagnostic interface connection (M12 4-pin) for software configuration via PC tool.
Key Materials and Components
▔▔
- Valve Body: High-density, fine-grain cast iron treated with anti-corrosion phosphate coating to resist severe industrial environments and minimize thermal distortion.
- Spool and Sleeve Set: Hardened tool steel precision-ground and micro-lapped to micron tolerances, delivering optimal wear resistance, minimal internal leakage, and long operational service life.
- Internal Seals:
- Fluorocarbon (FKM/Viton): Standard high-temperature and chemical-resistant elastomer suited for synthetic fluids and elevated oil temperatures.
- Nitrile (NBR): Optional low-temperature elastomer for standard mineral oil-based applications.
- Solenoid Actuator Tube & Coil: Heavy-duty, pressure-tight armature tube with fully encapsulated, moisture-proof copper windings, offering high thermal stability under continuous duty cycles.
Packaging and Transport Protection
▔▔
- Individual Industrial Packaging: Each valve is thoroughly oil-flushed, sealed with plastic port protection plugs, and vacuum-sealed in heavy-duty anti-corrosion (VCI) moisture-proof bags.
- Anti-Vibration Protection: High-density molded EPE foam encasement inside a rigid corrugated outer box protects the precise spool assembly and onboard electronic connector pins from shock during transit.
- Bulk & Export Packaging: Multiple boxed units are stacked into reinforced plywood crates with ISPM-15 compliant heat-treated wood, banded with steel/PET strapping, and corner-protected to guarantee safe long-distance freight delivery.
Applications
▔▔- Injection Molding Machines: Controls the proportional speed and smooth position transition of clamping units and injection cylinders to prevent mechanical shock and flash defects.
- Metal Stamping and Hydraulic Presses: Manages proportional pressing speed and secondary pressure buildup profiles for deep drawing and precision metal forming.
- Die Casting Machinery: Regulates high-speed shot cylinder movements and core-pulling sequences under high shock and elevated thermal conditions.
- Industrial Automation & Robotics: Serves as the principal control valve for hydraulic actuators in heavy material handling manipulators, timber processing rigs, and test benches requiring continuous flow metering.
Related Models
▔▔
| Part Number / Model Code | Mounting Interface | Nominal Flow (L/min) | Spool Type | Feedback / Driver | Seal Material |
| BE06-B31-N-60 | NG06 / CETOP 03 | 12 | 4-Way, Closed Center | Standard PWM Driver | NBR |
| BE06-B32-V-60 | NG06 / CETOP 03 | 24 | 4-Way, Float Center | Standard PWM Driver | FKM (Viton) |
| BE06-E01-OBE-V | NG06 / CETOP 03 | 32 | 4-Way, Linear Metering | Onboard Electronics (OBE) | FKM (Viton) |
| BE10-B31-N-50 | NG10 / CETOP 05 | 60 | 4-Way, Closed Center | Standard PWM Driver | NBR |
| BE10-E02-OBE-V | NG10 / CETOP 05 | 80 | 4-Way, High-Flow Spool | Onboard Electronics with LVDT | FKM (Viton) |
FAQ
▔▔Q1: How do I select or confirm the correct Parker BE model code for my system?
A: You need to confirm five key parameters: subplate interface size (NG06 or NG10), maximum flow requirement at your operational pressure drop, spool center function (closed, open, or float), control signal type (analog voltage/current or fieldbus), and seal compatibility with your hydraulic oil. Contact our technical team with your existing valve nameplate photo or hydraulic schematic for instant cross-referencing.
Q2: What hydraulic oil cleanliness level is required for reliable operation?
A: To prevent spool binding and maintain precise proportional control, oil cleanliness should be maintained at ISO 4406 class 18/16/13 or better. We recommend installing a 10-micron absolute filter in the system return or pressure line.
Q3: What type of hydraulic oil is compatible with the Parker BE Series?
A: Standard units equipped with NBR seals are compatible with mineral oil-based hydraulic fluids (HLP/HM according to DIN 51524). For synthetic fluids, fire-resistant fluids (HFD-U), or high-temperature operations above 60°C, select models configured with Viton (FKM) seals.
